Bartók Apex DAC & headphone amp

  • New

Bartók Apex DAC & headphone amp

The dCS Bartók APEX combines cutting-edge digital technology, the renowned Ring DAC™, and a high-end headphone amplifier to deliver uncompromising sound quality and exceptional versatility in your high-end audio system.

dCS
Sorry, This item is out of stock.
Color: black
€25,000.00
Tax included
Questions?

Request Special Price

Please enter your email address to receive your special price:

Success!

Your special price has been sent to your email!

Please check your inbox for the discount code and link.

Notice

  • Authorized Dealer: By original manufacturer or local distributor Authorized Dealer: By original manufacturer or local distributor
  • Terms Of Delivery: Free shipping and free returns Terms Of Delivery: Free shipping and free returns
  • Return Conditions: 30 days money-back guarantee Return Conditions: 30 days money-back guarantee
  • Visa, Mastercard, Google Pay, Apple Pay & PayPal -  Even in multiple rates! Visa, Mastercard, Google Pay, Apple Pay & PayPal - Even in multiple rates!

dCS Bartók APEX

Reference-class DAC, streamer & headphone amplifier


The dCS Bartók APEX embodies the very best of British engineering and audiophile passion. Built on decades of high-end expertise, it brings the transparency, musical insight and technical innovation associated with the legendary Vivaldi and Rossini ranges into a single, elegant unit.

Designed for the most demanding music lovers, Bartók APEX combines state-of-the-art digital technology, the acclaimed dCS Ring DAC™, an exceptionally capable headphone amplifier, a flexible streaming architecture and extensive connectivity. Whether used as a pure DAC, an all-in-one solution for headphones, or as the digital hub of a reference hi-fi system, Bartók APEX sets new standards for flexibility, build quality and musical expression.


Key Highlights & Features

  • Latest dCS Digital Processing Platform with sophisticated algorithms for maximum signal purity and flexibility
  • Exclusive dCS Ring DAC™ topology, continuously refined and further improved in the APEX version
  • Seamless high-end streaming from TIDAL, Qobuz, Deezer and internet radio via the dCS Mosaic Control app
  • Roon Ready, AirPlay, Spotify Connect and UPnP for compatibility with virtually any music source
  • Comprehensive digital inputs (USB, AES, Dual AES, S/PDIF) – ideal for streamers, CD transports and more
  • Powerful headphone amplifier for low- and high-impedance headphones; balanced and unbalanced outputs
  • Supports encrypted SACD data from dCS transports via Dual AES
  • Multi-stage DXD upsampling, optional DSD upsampling and selectable PCM/DSD filters for precise voicing
  • Innovative Auto-Clock system for effortless operation and extremely low jitter
  • Separate power supplies with dual transformers ensure strict isolation between DAC and amplifier sections
  • Firmware upgradable – future-proof with regular software and feature updates

World-class sound, effortlessly musical

Bartók APEX elevates digital playback to a new level. With remarkable transparency it reveals the finest details, hidden textures and dynamic nuances, while creating a natural, unforced soundstage that makes you rediscover familiar recordings.

Its ability to reproduce everything from explosive dynamics to the most delicate micro-detail with total control makes it a perfect match for audiophile headphones, active monitors or traditional stereo systems. Tone colour, timing and spatial imaging are as precise as they are emotionally engaging.


Master craftsmanship & intelligent design

Each unit is built by skilled specialists in Cambridgeshire, UK, with meticulous attention to detail. The solid aluminium chassis reflects exceptional manufacturing quality and protects the sensitive electronics from external influences.

A modular construction and advanced software architecture ensure Bartók APEX stays current not just today, but for years to come — performance and feature updates can be installed easily via firmware.


Intuitive control & maximum flexibility

With the dCS Mosaic app you can manage streaming services, digital sources and system options from one intuitive interface — on iOS, Android or tablet.

Bartók APEX supports virtually all relevant formats, offers native DSD and DoP, enables true 24-bit streaming over Ethernet, and provides numerous filters and upsampling options to tailor the sound to your preference.

The result: a versatile digital centerpiece that combines reference performance, future-proof architecture and captivating musicality.


Technical Specifications

Type Upsampling network DAC with headphone amplifier
Finish Silver or Black
Dimensions 444 mm (W) × 430 mm (D) × 115 mm (H) / 17.5" × 17.0" × 4.6"
Allow additional depth for cable connectors
Weight 16.7 kg / 36.8 lbs
DAC topology dCS proprietary Ring DAC™ topology
Digital inputs Ethernet RJ45 (up to 24-bit/384 kHz PCM, DSD64 & DSD128 DFF/DSF)
USB 2.0 Type-B (up to 24-bit/384 kHz PCM, DSD64 & DSD128 DoP)
USB OTG (up to 24-bit/384 kHz PCM, DSD64 & DSD128 DoP)
AES/EBU (up to 24-bit/192 kHz PCM, DSD64 & DSD128 DoP)
Dual AES (up to 24-bit/384 kHz PCM, DSD64 & DSD128 DoP)
S/PDIF (RCA, BNC, Toslink, up to 24-bit/192 kHz PCM, DSD64 DoP)
Analog outputs 1 × balanced (XLR), output levels: 0.2 V / 0.6 V / 2 V / 6 V RMS
1 × unbalanced (RCA), output levels: 0.2 V / 0.6 V / 2 V / 6 V RMS
Min load: 600 Ω (XLR), 52 Ω (RCA), recommended: 10 kΩ–100 kΩ
Headphone outputs 1 × 4-pin XLR (balanced)
1 × 6.35 mm (1/4") jack
Full-scale: 1.4 W RMS @ 33 Ω, 0.15 W RMS @ 300 Ω
Minimum headphone impedance: 33 Ω
Power consumption 30 W typical / 50 W maximum

Technical Specifications – dCS Bartók APEX

Type Upsampling network DAC with headphone amplifier
Colour Silver or Black
Dimensions 444mm (W) × 430mm (D) × 115mm (H) / 17.5" × 17.0" × 4.6"
Please allow extra depth for cable connectors
Weight 16.7 kg / 36.8 lbs
Converter Type dCS proprietary Ring DAC™ topology
Digital Inputs Ethernet RJ45 (up to 24-bit/384kHz PCM, DSD/64 & DSD/128 in DFF/DSF format)
USB 2.0 type-B (up to 24-bit/384kHz PCM, DSD/64 & DSD/128 DoP)
USB On-The-Go (up to 24-bit/384kHz PCM, DSD/64 & DSD/128 DoP)
AES/EBU (up to 24-bit/192kHz PCM, DSD/64 & DSD/128 DoP)
Dual AES (up to 24-bit/384kHz PCM, DSD/64 & DSD/128 DoP)
SPDIF (RCA, BNC, Toslink, up to 24-bit/192kHz PCM, DSD/64 DoP)
Analogue Outputs 1 × balanced pair (XLR), output levels: 0.2V, 0.6V, 2V, 6V RMS
1 × unbalanced pair (RCA), output levels: 0.2V, 0.6V, 2V, 6V RMS
Minimum load: 600Ω (XLR), 52Ω (RCA), recommended: 10k–100kΩ
Headphone Outputs 1 × stereo balanced 4-pin XLR
1 × stereo 6.35 mm (1/4") jack
Full-scale output: 1.4 W RMS into 33Ω, 0.15 W RMS into 300Ω
Minimum headphone impedance: 33Ω
Wordclock I/O 2 × Word Clock inputs (BNC), accepts standard word clock at 44.1, 48, 88.2, 96, 176.4, or 192kHz
1 × Word Clock output (BNC, TTL-compatible)
MQA Full decoding and rendering of MQA data from network and USB inputs
Residual Noise 24-bit data: Better than –113dB (20Hz–20kHz, unweighted, 6V output setting)
L/R Crosstalk Better than –115dB (20Hz–20kHz)
Spurious Responses Better than –105dB (20Hz–20kHz)
Filters Up to 6 PCM filters for different sonic characteristics
DSD mode: 4 filters for noise shaping; Filter 5 with improved transient response
Conversion User-selectable PCM upsampling to DXD, DSD or DSDx2
Software Updates Download and install via dCS Mosaic Control app
Local Control dCS Mosaic Control app
RS232 interface (for 3rd party automation)
dCS Universal Remote available as an option
Power Supply Factory set to either 100, 115/120, 220 or 230/240V AC, 50/60Hz
Power Consumption 30 Watts typical / 50 Watts maximum
